• 65"
  • Multi-Touch Screen
  • Powered by Android

Interactive classroom display

Maximise engagement and inspire collaboration with an interactive Philips T-Line display. Featuring anti-glare toughened glass, these Android-powered displays are made to withstand heavy daily usage and feature up to 20 touchpoints

Featuring multi-touch technology

  • 65"
  • Powered by Android
  • Multi-touch

OPS slot allows for PC embedding without cabling
Integrate a full-power PC or Android-powered CRD50 module directly into your Philips Professional Display. The OPS slot contains all the connections you need to run your slot-in solution, including a power supply.

Operate, monitor and maintain with CMND and Control
Run your display network over a local (LAN) connection. CMND and Control allows you to perform vital functions like controlling inputs and monitoring display status. Whether you're in charge of one screen or 100.

Multi-touch technology capable of 20 touchpoints
Create a memorable interactive experience with up to 20 touchpoints at the same time. Perfect for collaborative and competitive applications, this display connects your audience with any content - making it ideal for education, public venues, corporate, hospitality and retail settings. The touch panel is HID compliant, providing true plug-and-play operation.

Whiteboard mode built in
Inspire agile collaboration with whiteboard mode. Simply activate this feature to turn your display into a blank canvas that can be drawn on by multiple users by hand or with dedicated display markers. Everything on the screen can then be captured for easy printing or file sharing.

Wireless screen sharing and advanced collaboration
Display four feeds on the one screen. Wireless screen sharing allows you to connect multiple devices at the same time for quick content switching when you need it. Use your existing Wi-Fi network to instantly and securely connect devices or use our optional HDMI interact dongles to cast directly to the screen without needing to connect to your secured/protected network.

Android: Run your own app or choose your favourite app to run
With Android OS integrated into the display, you can work with the most developed OS on the planet and save your own app directly into the display. Or, choose from the large library of Android apps and play content from there. With the built-in scheduler, you can daypart your apps and content based on your customer and time of day and with the auto-orientation feature, showing content in portrait or landscape is as simple as turning the display.

Display Screens
Display Size 65"
Series T-Line
Display
Display diagonal 165.1 cm (65")
Display technology IPS
Display resolution 3840 x 2160 pixels
Display brightness 420 cd/m²
HD type 4K Ultra HD
Touchscreen Y
Number of simultaneous touchpoints 20
Multi-touch Y
Native aspect ratio 16:9
Response time 9 ms
Contrast ratio (typical) 1300:1
Contrast ratio (dynamic) 500000:1
Viewing angle, horizontal 178°
Viewing angle, vertical 178°
Display number of colours 1.07 billion colours
Pixel pitch 0.372 x 0.372 mm
Display diagonal (metric) 163.9 cm
Native refresh rate 60 Hz
Ports & interfaces
HDMI ports quantity 8
HDMI version 2.0
HDMI input ports quantity 6
HDMI output ports quantity 2
DVI port Y
DVI-I ports quantity 1
DVI-D ports quantity 1
DisplayPorts quantity 2
DisplayPorts in 1
DisplayPorts out 1
USB port Y
USB ports quantity 7
USB version 2.0/3.2 Gen 1 (3.1 Gen 1)
USB connector type USB Type-C
Ethernet LAN Y
Ethernet LAN (RJ-45) ports 1
Wi-Fi Y
RS-232C Y
Card reader integrated Y
Compatible memory cards MicroSD (TransFlash)
Audio
Built-in speaker(s) Y
Number of built-in speakers 2
RMS rated power 40 W
Design
Product design Digital signage flat panel
Placement supported Indoor
Orientation Horizontal/Vertical
Product colour Black
VESA mounting Y
Panel mounting interface 100 x 100 mm
Anti-glare screen Y
Performance
Purpose Universal
On Screen Display (OSD) Y
Number of OSD languages 18
On Screen Display (OSD) languages Arabic, Simplified Chinese, Traditional Chinese, Danish, German, Dutch, English, Spanish, Finnish, French, Italian, Japanese, Norwegian, Polish, Portuguese, Russian, Swedish, Turkish
Open Pluggable Specification (OPS) Y
Mean time between failures (MTBF) 50000 h
Power
Power consumption (typical) 175 W
Power consumption (standby) 0.5 W
Power consumption (max) 350 W
AC input voltage 100 - 240 V
AC input frequency 50 - 60 Hz
Computer system
Computer system N
Built-in processor Y
Processor model MTK5680
Internal memory 4 GB
Internal storage capacity 32 GB
Operating system installed Android 9.0
Video formats supported ASF, AVI, DAT, FLV, MKV, MP4, MPEG, MPG, TS, VOB, WEBM, WMV
Audio formats supported AAC, M4A, MP3, WMA
Image formats supported BMP, JPEG, JPG, PNG
Weight & dimensions
Width 1494.3 mm
Depth 80.2 mm
Height 869.4 mm
Weight 43.6 kg
Packaging content
Remote control included Y
Batteries included Y
Cables included AC, DVI, HDMI, IR sensor, RS-232
Operational conditions
Operating temperature (T-T) 0 - 40 °C
Operating relative humidity (H-H) 20 - 80%
Storage temperature (T-T) -20 - 60 °C
Storage relative humidity (H-H) 5 - 95%
Operating altitude 0 - 3000 m
Certificates
Certification CB BSMI EAC EMF PSB ETL
Features
Wall mountable Y
Technical details
Energy saving functions Smart Power
Keyboard control Hidden, Lockable
Picture enhancement 3/2 - 2/2 motion pull down, 3D Combfilter, Motion compens. deinterlacing, Progressive scan, 3D MA deinterlacing, Dynamic contrast enhancement
Signal loop through DisplayPort, RS232, IR Loopthrough
Picture performance Advanced color control
Surface treatment Anti-Glare coating
Sustainability compliance Y
Sustainability certificates CE, RoHS
Warranty period 5 year(s)
Other features
Quick start guide Y
Network controllable RS232/RJ-45
Glass protection Y
Screen saving functions Y
DisplayPort version 1.2
Screws included Y
Bezel width 1.63 cm
Plug and Play Y




PHILIPS 65" T-LINE ANDROID UHD HEIR 20 POINTS

  • Brand: Philips
  • Product Code: 65BDL3652T/00
  • Availability: .
  • Product PDF Product PDF
