The ThinkCentre M60e Tiny desktop crams serious performance into a diminutive package. At just 1L, it’s made to blend seamlessly into today’s shifting and shrinking workspaces. The M60e makes big ideas possible with up to 10th Gen Intel® Core™ i5 processors, bringing much-needed performance, speed, and potential to every desk.
| Desktop PC |
| Colour |
Black |
| Form Factor |
Tiny Form Factor |
| Graphics |
Integrated |
| Networking |
Bluetooth, WiFi, Ethernet |
| Operating System |
Windows 11 Pro |
| Processor |
Intel i3 |
| RAM |
8 GB |
| Storage Capacity |
256 GB SSD |
| Processor |
|---|
| Processor manufacturer | Intel |
| Processor generation | 10th gen Intel® Core™ i5 |
| Processor model | i3-1005G1 |
| Processor family | Intel® Core™ i3 |
| Processor cores | 2 |
| Processor frequency | 1.2 GHz |
| Processor boost frequency | 3.4 GHz |
| Processor cache | 4 MB |
| Processor cache type | Smart Cache |
| Processor threads | 4 |
| Configurable TDP-down | 13 W |
| Configurable TDP-down frequency | 0.9 GHz |
| Number of processors installed | 1 |
| Memory |
|---|
| Internal memory | 8 GB |
| Maximum internal memory | 32 GB |
| Internal memory type | DDR4-SDRAM |
| Memory layout (slots x size) | 1 x 8 GB |
| Memory slots | 2x SO-DIMM |
| Memory clock speed | 2666 MHz |
| Memory channels | Dual-channel |
| Storage |
|---|
| Total storage capacity | 256 GB |
| Storage media | SSD |
| Optical drive type | N |
| Total SSDs capacity | 256 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 256 GB |
| SSD interface | PCI Express 3.0 |
| NVMe | Y |
| SSD form factor | M.2 |
| Graphics |
|---|
| Discrete graphics card | N |
| Discrete graphics card model | Not available |
| On-board graphics card | Y |
| On-board graphics card model | Intel® UHD Graphics |
| Network |
|---|
| Ethernet LAN | Y |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Cabling technology | 10/100/1000Base-T(X) |
| Wi-Fi | Y |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Wi-Fi standards | Wi-Fi 6 (802.11ax) |
| WLAN controller manufacturer | Intel |
| WLAN controller model | Intel Wi-Fi 6 AX201 |
| Antenna type | 2x2 |
| Bluetooth | Y |
| Bluetooth version | 5.1 |
| Ports & interfaces |
|---|
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| HDMI ports quantity | 1 |
| DisplayPorts quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Combo headphone/mic port | Y |
| Design |
|---|
| Chassis type | mini PC |
| Volume | 1 L |
| Cable lock slot | Y |
| Cable lock slot type | Kensington |
| Product colour | Black |
| Viewing window | N |
| Performance |
|---|
| Motherboard chipset | Intel SoC |
| Audio system | High Definition Audio |
| Built-in speaker(s) | Y |
| Password protection | Y |
| Password protection type | HDD, Power on, Supervisor |
| Trusted Platform Module (TPM) | Y |
| Product type | Mini PC |
| Software |
|---|
| Operating system installed | Windows 11 Pro |
| Operating system architecture | 64-bit |
| Operating system language | English |
| Processor special features |
|---|
| CPU configuration (max) | 1 |
| Power |
|---|
| Power supply | 65 W |
| Operational conditions |
|---|
| Operating temperature (T-T) | 5 - 35 °C |
| Storage temperature (T-T) | -40 - 60 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 10 - 90% |
| Operating altitude | 0 - 3048 m |
| Non-operating altitude | 0 - 12192 m |
| Certificates |
|---|
| Certification | MIL-STD-810G |
| Sustainability |
|---|
| Sustainability certificates | RoHS |
| Weight & dimensions |
|---|
| Width | 179 mm |
| Depth | 182.9 mm |
| Height | 36.5 mm |
| Weight | 1.25 kg |
| Packaging content |
|---|
| Display included | N |
| Mouse included | Y |
| Keyboard included | Y |
