- 21.5"
- FHD 1920 X 1080px
- Cable lock slot, Wall Mountable, Tilt Adjustment
This LED-backlit monitor delivers a solid performance for standard office and home applications. Coming in a classy black texturised finish, the tiltable widescreen model is equipped with an HDMI port and a fast-reacting TN panel, boasting a 5 ms pixel response time for crisp, blurfree images. Intelligent programs such as Screen+ and i-Menu enhance the user experience and help to save energy. The eco-friendly Series 70 fulfils demanding sustainability certificates such as Energy Star 6.0 and EPEAT Silver and is prepared for both VESA wall mount and Kensington security devices. Discover all benefits of the series 70 monitors now!
| Monitors | |
| Panel Resolution | 1920x1080 |
| Screen Size | 21.5" |
| Refresh Rate | 60 Hz |
| Interfaces & Ports | HDMI, VGA |
| Speakers | No |
| Colour | Black |
| Display | |
|---|---|
| Display diagonal | 54.6 cm (21.5") |
| Display resolution | 1920 x 1080 pixels |
| HD type | Full HD |
| Native aspect ratio | 16:9 |
| Panel type | TN |
| Backlight type | W-LED |
| Touchscreen | N |
| Display brightness (typical) | 200 cd/m² |
| Response time | 5 ms |
| Display surface | Matt |
| Screen shape | Flat |
| Supported graphics resolutions | 1920 x 1080 (HD 1080) |
| Supported video modes | 1080p |
| Aspect ratio | 16:9 |
| Contrast ratio (typical) | 700:1 |
| Contrast ratio (dynamic) | 20000000:1 |
| Maximum refresh rate | 60 Hz |
| Viewing angle, horizontal | 90° |
| Viewing angle, vertical | 65° |
| Display number of colours | 16.7 million colours |
| Pixel pitch | 0.248 x 0.248 mm |
| Horizontal scan range | 30 - 83 kHz |
| Vertical scan range | 50 - 76 Hz |
| Viewable size, horizontal | 47.7 cm |
| Viewable size, vertical | 26.8 cm |
| Digital horizontal frequency | 30 - 83 kHz |
| Display diagonal (metric) | 54.61 cm |
| Surface hardness | 3H |
| 3D | N |
| Pixel frequency | 108 MHz |
| Performance | |
| NVIDIA G-SYNC | N |
| Multimedia | |
| Built-in speaker(s) | N |
| Built-in camera | N |
| Design | |
| Market positioning | Home |
| Product colour | Black |
| Front bezel colour | Black |
| Feet colour | Black |
| Heavy metals free | Hg (mercury) |
| Certification | True |
| Ports & interfaces | |
| Built-in USB hub | N |
| VGA (D-Sub) ports quantity | 1 |
| DVI port | N |
| HDMI ports quantity | 1 |
| HDMI version | 1.4 |
| Headphone out | Y |
| Headphone outputs | 1 |
| Headphone connectivity | 3.5 mm |
| HDCP | N |
| AC (power) in | Y |
| Ergonomics | |
| VESA mounting | Y |
| Panel mounting interface | 100 x 100 mm |
| Cable lock slot | Y |
| Cable lock slot type | Kensington |
| Height adjustment | N |
| Tilt angle range | -5 - 15° |
| On Screen Display (OSD) | Y |
| On Screen Display (OSD) languages | Simplified Chinese, Traditional Chinese, Croatian, Czech, German, Dutch, English, Spanish, Finnish, French, Italian, Japanese, Korean, Polish, Portuguese, Russian, Swedish, Turkish, Ukrainian |
| Plug and Play | Y |
| Tilt adjustment | Y |
| Power | |
| Energy efficiency class (SDR) | E |
| Energy consumption (SDR) per 1000 hours | 16 kWh |
| Power consumption (typical) | 19 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (off) | 0.5 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Energy efficiency scale | A to G |
| External power adapter | N |
| Packaging content | |
| Stand included | Y |
| Cables included | AC, HDMI, VGA |
| HDMI cable length | 1.5 m |
| Power cable length | 1.2 m |
| Weight & dimensions | |
| Width (with stand) | 503.4 mm |
| Depth (with stand) | 48 mm |
| Height (with stand) | 375 mm |
| Weight (with stand) | 2.7 kg |
| Width (without stand) | 503.4 mm |
| Depth (without stand) | 48 mm |
| Height (without stand) | 311.1 mm |
| Packaging data | |
| Package width | 558 mm |
| Package depth | 108 mm |
| Package height | 394 mm |
| Package weight | 3.45 kg |
| Package type | Box |
| VGA cable length | 1.2 m |
| Sustainability | |
| Sustainability certificates | RoHS, EPEAT Silver, ENERGY STAR |
| Logistics data | |
| Harmonized System (HS) code | 85285210 |
| Other features | |
| On/off switch | Y |
| TV tuner integrated | N |
| Exterior finish type | Textured |
| Recyclable packaging material | 100% |
| Bezel thickness type | Normal |
| Mean time between failures (MTBF) | 50000 h |
| Light effects | N |
test
AOC 21.5” B2C FHD VGA HDMI 60HRZ 5MS TILT VALUE RANGE -++
- Brand: AOC
- Product Code: E2270SWHN
- Availability: .
- Product PDF
