- Inputs: HDMI 1.4 x 1, VGA, DVI
- 1920x1080@75Hz resolution
- 20M:1 Contrast Ratio Dynamic
- 250 cd/m² Brightness
- 4ms Response Time
- 178/178º Viewing Angle
- -5/21.5 °Tilt
- Frameless, Wide viewing angle , Vesa
Thin and sleek 23.8” VA monitorwith lively colours, wide anglevisibility and eye-friendlytechnology
The 24B2XDAM from the B2 Series employsa 23.8” Full HD VA panel offering wideviewing angles, accurate and lively coloursplus flexible connectivity. It features a slimprofile and a 3-sides borderless panel forseamless multi monitor setups.
| Monitors | |
| Panel Resolution | 1920x1080 |
| Screen Size | 24" |
| Refresh Rate | 75 Hz |
| Interfaces & Ports | HDMI, VGA, DisplayPort |
| Speakers | Yes |
| Colour | Black |
| Display | |
|---|---|
| Display diagonal | 60.5 cm (23.8") |
| Display resolution | 1920 x 1080 pixels |
| HD type | Full HD |
| Native aspect ratio | 16:9 |
| Display technology | LED |
| Panel type | VA |
| Backlight type | W-LED |
| Touchscreen | N |
| Display brightness (typical) | 250 cd/m² |
| Response time | 4 ms |
| Display surface | Matt |
| Anti-glare screen | Y |
| Screen shape | Flat |
| Supported graphics resolutions | 1280 x 720 (HD 720), 1920 x 1080 (HD 1080) |
| Supported video modes | 720p, 1080p |
| Aspect ratio | 4:3, 16:9 |
| Contrast ratio (typical) | 3000:1 |
| Contrast ratio (dynamic) | 20000000:1 |
| Maximum refresh rate | 75 Hz |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 16.7 million colours |
| Display diagonal (metric) | 60.452 cm |
| Surface hardness | 3H |
| Colour depth | 8 bit |
| sRGB coverage (typical) | 101% |
| NTSC coverage (typical) | 72% |
| Adobe RGB coverage | 74% |
| Performance | |
| NVIDIA G-SYNC | N |
| AMD FreeSync | N |
| Fast charging | N |
| Flicker-free technology | Y |
| Low Blue Light technology | Y |
| Multimedia | |
| Built-in speaker(s) | Y |
| Built-in camera | N |
| Number of speakers | 2 |
| RMS rated power | 2 W |
| Built-in microphone | N |
| Design | |
| Market positioning | Home |
| Product colour | Black |
| Frameless design | Y |
| Front bezel colour | Black |
| Detachable stand | Y |
| Feet colour | Black |
| Heavy metals free | Hg (mercury) |
| Country of origin | China |
| Certification | True |
| Ports & interfaces | |
| Built-in USB hub | N |
| VGA (D-Sub) ports quantity | 1 |
| DVI port | Y |
| HDMI | Y |
| HDMI ports quantity | 1 |
| HDMI version | 1.4 |
| Audio input | Y |
| Headphone out | Y |
| Headphone outputs | 1 |
| Headphone connectivity | 3.5 mm |
| Microphone in | Y |
| Ergonomics | |
| VESA mounting | Y |
| Panel mounting interface | 100 x 100 mm |
| Cable lock slot | Y |
| Cable lock slot type | Kensington |
| Height adjustment | N |
| Pivot | Y |
| Tilt angle range | -5 - 20° |
| On Screen Display (OSD) | Y |
| On Screen Display (OSD) languages | Simplified Chinese, Traditional Chinese, Croatian, Czech, German, Dutch, English, Spanish, Finnish, French, Italian, Japanese, Korean, Polish, Portuguese, Russian, Swedish, Turkish, Ukrainian |
| Number of OSD languages | 16 |
| Tilt adjustment | Y |
| Power | |
| Energy efficiency class (SDR) | F |
| Energy consumption (SDR) per 1000 hours | 21 kWh |
| Power consumption (typical) | 21 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (off) | 0.3 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Energy efficiency scale | A to G |
| External power adapter | Y |
| Packaging content | |
| Stand included | Y |
| Cables included | AC, HDMI |
| HDMI cable length | 1.8 m |
| Power cable length | 1.8 m |
| Weight & dimensions | |
| Width (with stand) | 539.5 mm |
| Depth (with stand) | 170.9 mm |
| Height (with stand) | 418.4 mm |
| Weight (with stand) | 2.7 kg |
| Width (without stand) | 539.5 mm |
| Depth (without stand) | 37.5 mm |
| Height (without stand) | 318.8 mm |
| Packaging data | |
| Package width | 592 mm |
| Package depth | 106 mm |
| Package height | 467 mm |
| Package weight | 4.5 kg |
| Package type | Box |
| Sustainability | |
| Sustainability certificates | ENERGY STAR |
| Logistics data | |
| Commodity Classification Automated Tracking System (CCATS) | 8528521000 |
| Harmonized System (HS) code | 85285210 |
| Other features | |
| Exterior finish type | Textured |
| Recyclable packaging material | 100% |
| Light effects | N |
test
AOC 24” FHD @ 75HZ VA 4MS SPKRS BLK HDMI 1.4 x 1, VGA, DVI
- Brand: AOC
- Product Code: 24B2XDAM
- Availability: .
- Product PDF
